[WildFLy] 서버 사용 포트 정리

WildFly에서 사용하는 포트정보이다.

사용하는 서비스에 맞게 방화벽 정책을 추가하여 통신이 원활히

진행할 수 있도록 참고한다.

Table 7.1. Reference of the default socket bindings
Name	Port (TCP)	Mulicast Port (UDP)	Description	full-ha-sockets	full-sockets	ha-socket	standard-socket
ajp	8009		Apache JServ Protocol. Used for HTTP clustering and load balancing.	Yes	Yes	Yes	Yes
http	8080		The default port for deployed web applications.	Yes	Yes	Yes	Yes
https	8443		SSL-encrypted connection between deployed web applications and clients.	Yes	Yes	Yes	Yes
jacorb	3528		CORBA services for JTS transactions and other ORB-dependent services.	Yes	Yes	No	No
jacorb-ssl	3529		SSL-encrypted CORBA services.	Yes	Yes	No	No
jgroups-diagnostics		7500	Multicast. Used for peer discovery in HA clusters.	Yes	No	Yes	No
jgroups-mping		45700	Multicast. Used to discover initial membership in a HA cluster.	Yes	No	Yes	No
jgroups-tcp	7600		Unicast peer discovery in HA clusters using TCP.	Yes	No	Yes	No
jgroups-tcp-fd	57600		Used for HA failure detection over TCP.	Yes	No	Yes	No
jgroups-udp	55200	45688	Unicast peer discovery in HA clusters using UDP.	Yes	No	Yes	No
jgroups-udp-fd	54200		Used for HA failure detection over UDP.	Yes	No	Yes	No
messaging	5445		JMS service.	Yes	Yes	No	No
messaging-group			Referenced by HornetQ JMS broadcast and discovery groups.	Yes	Yes	No	No
messaging-throughput	5455		Used by JMS Remoting.	Yes	Yes	No	No
mod_cluster		23364	Multicast port for communication between the JBoss Enterprise Application Platform and the HTTP load balancer.	Yes	No	Yes	No
osgi-http	8090		Used by internal components which use the OSGi subsystem.	Yes	Yes	Yes	Yes
remoting	4447		Used for remote EJB invocation.	Yes	Yes	Yes	Yes
txn-recovery-environment	4712		The JTA transaction recovery manager.	Yes	Yes	Yes	Yes
txn-status-manager	4713		The JTA / JTS transation manager.	Yes	Yes	Yes	Yes





참고글:

https://access.redhat.com/documentation/en-us/jboss_enterprise_application_platform/6/html/installation_guide/network_ports_used_by_jboss_enterprise_application_platform_62
